Ultron

A Robust Multi-Modal Sensor Fusion System

Ultron

A Robust Multi-Modal Sensor Fusion System

Why Ultron?

Ultron is a NVIDIA® Jetson powered Sensor Fusion System that brings high computing power to the edge for industrial and commercial applications that require logic-based decisions for automated processes and machines.

Edge computing platform

Computing platform that supports a variety of high-performance computing modules such as NVIDIA® Jetson Xavier™ NX.

Seamless communication

5G/LTE/Wifi options supported for high speed data transmission.

Advanced AI capabilities

Easily integrate machine learning (ML) or deep learning (DL) models with greater detection and prediction accuracy in machinery and automated robotics processes.

High interoperability

Interoperable with standard industrial and machine vision cameras for real time AI-enabled inference.

How it works

Programmable Logic Controllers (PLCs) are preferred over microcontrollers in industrial applications due to their reliability, flexibility, and robustness. We take PLCs a step further with Ultron's high computing power and low latency for AI vision applications in various settings. This makes Ultron perfectly designed for automations and autonomous infrastructures. The applicable industries include smart factories and industry 4.0, smart cities, intelligent traffic management systems, smart buildings, automated homes, and agriculture.

How it works diagram

Highlighted Features

Hardware

Expandable I/O units for building small to enterprise level autonomous infrastructure

Ultron Side View

Expandable I/O units for building small to enterprise level autonomous infrastructure

All-in-one platform for computer vision application and logic controller in a small form factor

Ultron Upright View

All-in-one platform for computer vision application and logic controller in a small form factor

Highlighted Features

Software Defined Architecture

Software defined architecture

User-friendly SDK/APIs simplify human and machine interfaces, allowing users to build faster.

software defined architecture image

Product Specifications

Get started

Supported Modules

NVIDIA Jetson Orin NX and Xavier NX

General

2x RJ45 ports -- the use of expandable IP cameras for video detection and analytic.network

Supports 5G/LTE/Wi-Fi wireless alternatives for comprehensive

Equipped inertial measurement unit (IMU) sensor for device security

I/O

Expandable up to 7 blocks

Rich Inputs & Outputs Capabilities:

4x Analog input, 0-10V

8x Digital isolated input, 5-24V

8x Digital isolated output relay, AC 250V/5A

4x Digital isolated phototransistor output, 5-24V

Expansion

2x Serial Ports (RS232/RS485)
lx USB3.1 TypeA
lx 12C
lx CAN Bus

Internal I/O

USB Type C x1 (OTG)

Automation Header(Reset/Recovery)

Dimension

100(W) x 76(L) x 112.5(H)mm

Supported Modules

NVIDIA® Jetson Xavier™ NX

General

2x RJ45 ports -- the use of expandable IP cameras for video detection and analyticscomprehensive network.
Supports 5G/LTE/Wi-Fi wireless alternatives for comprehensive network.
Equipped inertial measurement unit (IMU) sensor for device security

I/O

Expandable up to 7 blocks
Rich Inputs & Outputs Capabilities:
4x Analog input, 0-10V
8x Digital isolated input, 5-24V
8x Digital isolated output relay, AC 250V/5A4x
Digital isolated phototransistor output, 5-24V

Internal I/O

USB Type C x1 (OTG)
Automation Header(Reset/Recovery)

Dimension

100(W) x 76(L) x 112.5(H)mm

Use Cases

Get to know more about this product
